Black Box Network Services EVNSL0505MS-0025 CAT5e 350-MHz Shielded Solid Backbone PVC Cable - 24 AWG, White - 25 ft.

Picture of Black Box Network Services EVNSL0505MS-0025 CAT5e 350-MHz Shielded Solid Backbone PVC Cable - 24 AWG, White - 25 ft.

MSRP: $20.16

Price: $12.42

Availability: Out of stock

SKU: SY2894867

Manufacturer: Black Box Network Services

Lead Time:3

Be the first to review this product

Sorry - this product is no longer available

Features

350-MHz backbone cable for noisy CAT5e runs
Solid, dependable CAT5e backbone cable for new and existing networks
Ideal for use in data, audio, and video applications and for horizontal network connections
Cable construction - 24 AWG solid conductor, straight-pinned, 4-pair, T568B, molded hoods
Shielding - Mylar tape; tinned copper drain wire; aluminum/Mylar tape

Specifications

Color: White
ACR: 13.3 dB/100 m at 100 MHz
ACRF: 23.8 db/100 m at 100 MHz
Attenuation: 22.0 dB/100 m at 100 MHz
Cable Outside Diameter - Nominal: 0.2"
Capacitance Unbalance - Pair to Ground: 330 pF/100 m maximum
Conductor: 24 AWG, solid, bare copper
Delay Skew - Maximum: 45 ns/100 m
Impedance: 1000 ± 15%
Insulation: HDPE: 0.009"
Jacket: PVC; CM; RoHS compliant
NEXT: 35.3 dB/100 m at 100 MHz
Propagation Delay: 538 ns/100 m at 100 MHz
PS-ACR: 10.3 dB/100 m at 100 MHz
PS-ACRF: 20.8 dB/100 m at 100 MHz
PS-NEXT: 32.3 dB/100 m at 100 MHz
Return Loss: 20.1 dB/100 m at 100 MHz
Standards: UL 444; ISO/IEC 11801; TIA/EIA-568-B.2-1 CAT5e; 2002/95/EC
Temperature/Voltage Rating: 167° F at 300 Vá
HDPE insulation: 0.009"
Length: 25 ft.
Weight: 0.91 lbs

Products specifications

Attribute name	Attribute value
MPN	EVNSL0505MS-0025
Color	Copper
Size	25 ft
